QA13538
return
|
型號 Model |
軸承 Beaing Sleeve.Ball |
電壓 Voltage V |
輸入功率 Inputpower W |
頻率 Frequency HZ |
電流 Curent AMP |
轉(zhuǎn)速 Speed R/min |
風量 Air flow m3/min |
噪聲 Noise dB(A) |
絕緣電阻 Insulation Resistance |
耐壓 Resist Strength |
重量 Weinght KG |
|
QA13538HSL1 |
S |
110 |
23/21 |
50/60 |
0.30/0.28 |
2600/2900 |
3.0/3.4 |
55/57 |
AC1500V- 100MΩ |
1500 |
0.55 |
|
QA13538HSL2 |
S |
220 |
23/21 |
50/60 |
0.15/0.14 |
2600/2900 |
3.0/3.4 |
55/57 |
AC1500V- 100MΩ |
1500 |
0.55 |
|
QA13538HSL3 |
S |
380 |
23/21 |
50/60 |
0.12 |
2600/2900 |
3.0/3.4 |
55/57 |
AC1800V- 100MΩ |
1800 |
0.55 |
|
QA13538HBL1 |
B |
110 |
23/21 |
50/60 |
0.30/0.28 |
2600/2900 |
3.0/3.4 |
61/63 |
AC1500V- 100MΩ |
1500 |
0.55 |
|
QA13538BL2 |
B |
220 |
23/21 |
50/60 |
0.15/0.14 |
2600/2900 |
3.0/3.4 |
61/63 |
AC1500V- 100MΩ |
1500 |
0.55 |
|
QA13538HBL3 |
B |
380 |
23/21 |
50/60 |
0.12 |
2600/2900 |
3.0/3.4 |
61/63 |
AC1800V- 100MΩ |
1800 |
0.55 |
